Multifunction Electronic Energy Meter with LCD display

General Introduction

Multifunction Electronic Energy Meter with LCD display can measure the import and the export active energy, the inductive and the capacitive reactive energy, and is with TOU function. It has the anti-tamper function, it will alarm in time of detected tamper events, such as current reversal, voltage phase sequence reverse, meter cover open and terminal cover open, bypass, etc.

Technical specifications

Main functions

1. Metering and measurements: It can measure voltage, current, active power, reactive power, apparent power, power factor, etc. It can measure the import and export active maximum demand, and four quadrant reactive maximum demand. It is with high accuracy. Class 0.2S, Class 0.5S or Class 1.0 for kWh are available.

2. Display and indication: It adopts a large screen LCD with abundant graphics and hint text. The displayed contents can be scrolled automatically or by button, and the displayed items can be configured as per the requirements. It is with backlight. Meter can be read during power outage.

3. TOU: 4 tariffs; Built-in 2 sets of time zone tables and 2 sets of daily period tables, which can be configured as per the requirements. Moreover, the switching time for both 2 sets of time zone tables and 2 sets of daily period tables can be set and achieve the mutual switching. It can set 14 day period tables and 14 week tables and 100 public holidays.

4. Load profile: It can record the data of multi-channel load profile.

5. Anti-Tamper: The meter will alarm in time of detected the tamper events, such as current reversal, voltage phase sequence reverse, meter cover open and terminal cover open, bypass, etc.

6. Event logs: It can separately record latest 10 times events, such as power outage, programming, time correction, meter cover open, disconnection and reconnection, reset of events, reset of meter, etc.

7. Communication interface: The meter has one optical port, one RS485 and one RS232. These three interfaces are independent with each other.

Honorary Qualification

Each of honors accompanies each step of the growth of Risesun, but Risesun's people have always believed that honor only belongs to yesterday, and does not represent today and tomorrow, and all that we have now is to give us a reason to climb higher. For better tomorrow, Risesun's people work hard as always.

System advantages

1.Diversity of management:
Managing range covers the different types of energy consumed objects, such as Substations, Users with special transformer, Distribution transformers, Residential Users, etc. It can configure the relevant managing function according to the type of object.

2.Flexibility of configuration:
2.1 Function modularization: It can customize the equipment and separately deploy the modules according to the size of the management scale.
2.2 The function is hierarchically designed, which can guarantee clear logic, convenient maintenance and the stable operation.

3.Compatibility of equipments:
The users can choose the appropriate mode of network (such as GPRS, PLC, WSN or 485), the collection equipments (such as various energy meters or concentrators) and the operation protocol of equipments according to their own situation. The system can provide support or expansion.

Zhejiang Risesun Science and Technology Co., Ltd.is a famous professional supplier of energy measuring meters and acquisition systems of consumed energy information, and it is a national level high and new technology enterprise with the business range of research and development, production, sale and after-sales service for energy measuring meters and acquisition systems of consumed energy information. Its main products cover smart energy meter, din rail energy meter, STS keypad prepaid energy meter, multifunction energy meter, acquisition terminal of special transformer, data acquisition system, charging pile of electric auto, metering box and etc. It is one of the companies with the most technical influence and development potential in the electric energy metering instrument industry of China.

Risesun is one of the earliest enterprises in meter industry forming  Management System of ISO9001:2008, ISO14001: 2004 and OHSAS18001: 2007. Moreover, a variety of leading products have passed quality certifications of the international authoritative organizations like the Holland KEMA, the European Union CE-MID, South Africa STS, Switzerland DLMS and etc.

Risesun has formally carried out the globalization management strategy. Its sales turnover has increased steadily year by year, with sales reaching 3 billion yuan in the past three years. Its products and solutions have already been successfully applied in a number of countries and regions, and have obtained the unanimous praises from customers. A main source of its sales revenues in the future will be from the international trade business.

Today's Risesun, just as a round of Oriental Sun, is rising and creating greater glories with the help of the national macroscopic policy good solution and its research and development potential.
